| Brand | NTN |
|---|---|
| Weight | 0.210000 |
| Product Category | Tapered roller bearings |
| Inner (mm) | 28.575 |
| Outer (mm) | 57.15 |
| Width (mm) | 17.462 |
| Seal | None, open bearing |
| Cage | Sheet steel cage |
4T-15590/15520-NTN
Product Category
Tapered roller bearings
SKU
400-07800
£33.59
£27.99
Ships in 5-6 working days
·
8
pcs
UK & Ireland delivery · 1-2 working days.
Same day dispatch on orders before 4:30pm
Need it sooner? Contact our Sales Team
| Bore | Cylindrical bore |
|---|---|
| Roller Rows | Single row bearing |
| Rings Material | Case-hardened Steel |
| Temperature Range | -40 to +120°C |
| Arrangement | Standard version |
| B - Width Of Inner Ring (mm) | 17.462 |
| C - Width Of Outer Ring (mm) | 13.495 |
| r - Housing Radius Max (mm) | 1.5 |
| R - Shaft Radius Max (mm) | 3.5 |
| Bearing Type | Cone/Cup |
| Limit Speed Oil (rpm) | 8900 |
| Limit Speed Grease (rpm) | 6700 |
| Dyn. Load Rating (kn) | 44 |
| Stat. Load Rating (kn) | 46 |
| Tolerance Class | Tolerance class P0/PN2 / ABEC 1 |
| Iso | ISO 355 |
Need help or advice? Talk to our experts Contact us
Product Substitutes
Product
Dimensions
Availability
Unit price (Ex VAT)
-
4T-15520-NTN
Tapered roller bearings
Dimensions: 0 x 57.15 x 13.4955-6 days: · 83 pcs£12.83 £10.69 -
-
4T-15590-NTN
Tapered roller bearings
Dimensions: 28.575 x 0 x 17.4625-6 days: · 6 pcs£20.78 £17.32
